应用
2835直下式应用-尊龙凯时平台版
产品介绍：
对于直下式而言，是把led做成密集的点阵，放置在屏幕的背后，直接照射屏幕，因此也叫直射式
场景图：
|
series |
size(mm) |
if |
power |
chip# |
flux（typ) |
status |
cct |
ntsc |
application |
|
2835-2.5 |
2.8×3.5×0.8t |
400ma |
1.2-1.5w |
2p |
140lm |
mp |
0.285,0.260 |
68%-72% |
od25 |
|
pct |
direct-lit |
||||||||
|
3030-2.6 |
3.0x3.0x0.52t |
600ma |
2.0w |
2p |
175lm |
mp |
0.285,0.260 |
68%-72% |
od25 |
|
emc |
300ma |
2.0w |
2s |
175lm |
mp |
0.285,0.260 |
68%-72% |
direct-lit |
|
|
3030-2.1 |
3.0x3.0x0.65t |
600ma |
2.0w |
2p |
172lm |
mp |
0.285,0.260 |
68%-72% |
od20 |
|
emc |
300ma |
2.0w |
2s |
172lm |
mp |
0.285,0.260 |
68%-72% |
direct-lit |
|
|
1313 |
1.3x1.3x0.35 |
700ma |
2.5w |
1 |
192lm |
mp |
0.285,0.260 |
68%-72% |
od30 |
|
csp |
direct-lit |
